RAB Lighting

RAB H17S 100W LED High Bay Selectable Wattage & CCT

RAB H17S 100W LED High Bay Selectable Wattage & CCT

Regular price $128.00
Regular price Sale price $128.00
Sale Sold out
Shipping calculated at checkout.
Color: Black
Wattage
Color Temperature

H17S High Bay

The newest generation of the H17 may be smaller and lighter, but it still packs a powerful punch. With a body size less than a foot in diameter, the entire family offers incredibly high output, replacing up to 1500W MH at an even higher efficacy. Plus, there are now four models to choose from including two new power packages, making it even more versatile for any application. Experience even more control with three selectable wattages and three CCTs. The H17 also features an expansion port for easy addition of standard or Lightcloud Blue-enabled PIR and microwave sensors, allowing for customized brightness and hold time settings for energy and cost savings. For added convenience, a remote is also available. Emergency battery backup? No problem. With Lightcloud Blue technology, you can easily conduct monthly and annual testing right from your phone, saving valuable time. And to top it off, there are a variety of accessories such as reflectors, refractors, lenses, wire guards, and mounting options to

  • Selectable power, and CCT
  • Available models & wattages: H17S: 100/80/60W
  • Selectable CCT: 3000/4000/5000K adjustable
  • Suitable for wet locations
  • Comes with expansion port for sensors
  • PIR and microwave sensor kits available
  • Kits available for surface mount or pendant mount
  • DLC Premium listed
  • 5-years, limited warranty
  • Available accessories: Aluminum and polycarbonate reflector,
    wire guard and drop lens available for H17S, H17, H17XL
    Aluminum reflector, wireguard available for H17XXL



Spec Sheet

Family Spec Sheet

Black Spec Sheet / White Spec Sheet

Installation Instructions


Info
Product Type  UFO High Bay
Wattage 60/80/100W
Lumen 9,205-14,959 lm
Efficacy 143.1-169.9 lm/W
Color Temp. 3000K 4000K 5000K
CRI 81-83 CRI
L70 Lifespan 50,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
Housing Precision die-cast aluminum
Finish  Black | White
Mounting Comes standard with a hanging hook and a 6-foot cord. Heavy-duty 3/4"-14 NPT hook and 3/4"-14 pendant mount capable (pendant by others)
Reflector
Polycarbonate and Aluminum (Reflector Accessories Sold Separately)
Lens Polycarbonate lens
IP Rating Ingress protection rating of IP65 for dust and water
Additional Info



                                                Compliance
UL Listed Suitable for wet locations. Ingress protection rating of IP65 for dust and water
IESNA LM-79 & LM-80 Testing RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-47I1ZQ
                                                  Electrical
Driver See Spec Sheets
THD See Spec Sheets
Power Factor See Spec Sheets
Dimming Driver Driver includes wiring for 0-10V dimming systems. Dim as low as 10%
Photocell 120-277V selectable photocell that can be turned on and off
