Dals Lighting FGM4-CDW-DUO Double 4" 18W Flat Gimbal Recessed Downlight Selectable CCT + Dim-to-Warm

Dals Lighting FGM4-CDW-DUO Double 4" 18W Flat Gimbal Recessed Downlight Selectable CCT + Dim-to-Warm

$94.32
$94.32
Sale Sold out
Shipping calculated at checkout.
Finish
Color Temperature
Wattage

Double 4" 18W Flat Gimbal Recessed Downlight Selectable CCT + Dim-to-Warm

The DALS FGM4-CDW-DUO puts two adjustable 4" flat gimbal heads in one housing. It delivers 1830 lumens at 18W with switch-selectable color temperature plus dim-to-warm, and the flat, low-profile trim sits flush against the ceiling. Each head aims independently for accent and wall washing.

  • 18W, 1830 delivered lumens at 3000K, CRI 92
  • Selectable CCT: 2700K / 3000K / 3500K / 4000K / 5000K, plus dim-to-warm 3000K-2200K
  • 40° beam angle, adjustable gimbal
  • Triac / ELV dimming
  • Wet location, IP65, indoor/outdoor, -20 to 40 °C
  • Polycarbonate optical lens, matte aluminum housing
  • ETL listed, Title 24, Energy Star, IC rated and air-tight
  • 5-year warranty
Dimensions
Cutout (In.) 8-5/8" x 4-5/8"

Spec Sheets

Spec Sheet

Catalog Sheet

Installation Instructions

Info
Product Type Flat Gimbal Recessed Downlight
Wattage 18
Lumen 1830
Color Temp. 2700/3000/3500/4000/5000k + DW 3000-2200k
CRI 92
Beam Angle 40°
Dimming Triac / ELV
L70 Lifespan >50,000 hours
Finish Black or White
Construction Aluminum housing
Lens Polycarbonate, Optical lens
Additional Info
Compliance
Certifications ETL listed, Title 24-JA8, Energy Star, IC rated, Air-tight (ASTM E283-04), UL-1598, CSA C22.2 No. 250.0, FCC Part 15 Class B
Location Wet location, IP65
Warranty 5-year limited
Electrical
Input Voltage 120 V
Power Factor 99%
Driver Constant current
Operating Temp. -20 to 40 °C
