Eaton
Eaton 7621W Single Pole Decorator Switch 20 AMP Anti Microbial
Eaton 7621W Single Pole Decorator Switch 20 AMP Anti Microbial
Regular price
$9.29
Regular price
$4.99
Sale price
$9.29
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Single Pole Decorator Switch 20 AMP
Eaton commercial grade decorator switch, Box, #14-10 AWG, 20A, Flush, 120/277V, Back/push, Antimicrobial paddle, Maintained, White, Motor Control, Fan, LED, Incandescent, ELV,MLV,CFL, Florescent, Halogen, Single-pole, Thermoplastic
- Tapered back wire openings handle multiple wire sizes and types for applications up to #10 AWG solid or stranded wire
- One-piece wrap around auto-grounding strap for ground integrity in severe conditions
- Welded construction provides superior assembly security under heavy use
- Stippled line and ground contacts ensure solid contact; ground screw clamp provides secure wiring and reduces installation time
- Tarnish resistant with minimal color change over time
| Length (in.) | 4.19" |
| Width (in.) | 1.20" |
| Depth (in.) | 1.39" |
| Weight (lbs) Each | .24 lbs |
Spec Sheet
Spec Sheet
Info
| Type | Decorator Switch |
| Connector Type |
Screw
|
| Switch Type |
Single-pole
|
| Compliance |
RoHS Compliant
|
| Certifications | cULus Listed |
| Color | White |
| Material | Polycarbonate |
Additional Info
| Load Type | Motor Control, HAL, LED, CFL, MLV, ELV, INC, Fan, FLR |
| Wiring Method | Back and push |
| Mounting | Flush |
| Wire Size | #14-10 AWG |
| VolTAGE | 120V |
| Amp. Rating | 20 A |
| Use | Residential |
| Actuator |
Antimicrobial paddle |
