GM Lighting NVM24S NeoVision Mini 24V 2W/FT Tape Light Neon Colors

$243.00

Sale Sold out

Shipping calculated at checkout.

Size 16FT

Color Temperature/ Color Amber Blue Green Red Orange

Quantity

NeoVision Mini 24V Tape

The NeoVision Mini LED Tape is a 24VDC flexible linear lighting solution with a slim 4mm profile. Designed for applications that demand ultra-rich light and color saturation, it features horizontal Side-Flex bending, allowing it to conform seamlessly to curvilinear surfaces and intricate designs. Available in 2700K, 3000K, and 4000K color temperatures, it delivers well-diffused, soft illumination with IP65-rated waterproofing for both indoor and outdoor use.

24VDC operation
2.0 watts per foot
Wet location – IP65
Multiple power feed options
Tape encased in UV stable silicone (UV protected)
Dimmable
Wireless control with LUXcontrol App and controller
2700K, 3000K or 4000K / Amber, Blue, Green, Orange or Red
120° viewing angle
Maximum run: 16’4”, custom cuts available
Field cuttable and joinable in 1-inch increments while retaining IP65
Tools required for capping and joining
Mounting clips included

Spec Sheets

Spec Sheet

Sell Sheet

Installation Instructions

Info

Catalog No.	Lumens per Foot	Color Temp.	Max. Run
NVM24S-2W-AM-16	14	AMBER	16' 4"
NVM24S-2W-BL-16	13	BLUE	16' 4"
NVM24S-2W-GR-16	59	GREEN	16' 4"
NVM24S-2W-RD-16	7	RED	16' 4"
NVM24S-2W-OR-16	15	ORANGE	16' 4"

*4' power feed at each end. 2x feeds. 2 end caps.

Accessories

Catalog No.	Description
NVM24S-EC	End Cap, Molded Silicone (sealant not included)
NVM24S-MC-A	Back Mounting Clips, Aluminum (20 clips, 20 SS screws)
NVM24S-CHL-A4	Rigid Channel, Aluminum, 4ft
NVM24S-FLEX-CHL	Flexible Channel, Stainless Steel, 1m 105 holes & screws
TAPE-DS-VHB-4MMW	4mm wide x 6m VHB tape
TOOL-PH0-HEX	PH0 Philips head, 1/4" hex drive bit
