GM Lighting
GM Lighting RSD-FR 4/6" Fire Rated Downlight Selectable CCT
GM Lighting RSD-FR 4/6" Fire Rated Downlight Selectable CCT
Regular price
$39.60
Regular price
Sale price
$39.60
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Description
120V RSD Fire Rated Selectable White Regressed Downlight
Solid steel construction is fire-rated and can mount in 2x 5/8″ Type X Sheetrock. Easy to install using included power supply with integrated junction box and modular jacks. These 4″ and 6″ regressed downlights feature shallow mount designs along with Title 24/JA8 and Energy Star ratings.
- This product has been tested to meet a 2-hour fire rating which complies with conditions of acceptability for UL 263, ASTM E119, CAN/ULC-S110
- 5CCT value selector switch
- Can mount in insulated ceilings up to 1.75″ thick
- Edge-lit technology for diode-free illumination
- Dimmable (Triac or ELV)
Spec Sheet
Info
| Catalog No. | Dimensions | Color | Wattage | CRI | Lumens in 3000K | Finish |
|---|---|---|---|---|---|---|
| RSD-4-FR-TUN-WH | 5-1/8″ Dia. Trim | 5CCT: 2700K, 3000K, 3500K, 4000K, 5000K | 12W | 90+ | 735lm | White |
| RSD-6-FR-TUN-WH | 6-7/8″ Dia. Trim | 5CCT: 2700K, 3000K, 3500K, 4000K, 5000K | 15W | 90+ | 975lm | White |
Additional Info
| Catalog No. | Description |
|---|---|
| RSD-TUN-5FT-EXT | 5’ extension cord for RSD Series Downlights |
| RSD-TUN-10FT-EXT | 10’ extension cord for RSD Series Downlights |
| RSD-TUN-20FT-EXT | 20’ extension cord for RSD Series Downlights |
| UNV-NCP | New construction plate for all RSD Series Downlights |
