2X4 Frame Panel Selectable CCT/Wattage

The Luxrite LR24166 is a 2x4 LED lay-in panel with selectable wattage and color temperature, making it a versatile and efficient choice for both commercial and residential ceiling grid systems. This single SKU offers flexibility to meet a variety of lighting needs, making it ideal for use in offices, schools, healthcare facilities, and commercial buildings. With its sleek and modern design, the LR24166 offers a combination of performance, energy savings, and configurable options for customers looking for high-performance lighting solutions.

• Wattage Selectable: 40W / 50W / 60W (up to 7800 lumens)

• 5CCT Selectable: 3000K / 3500K / 4000K / 5000K / 6500K

• 0-10V Dimmable

• High Efficacy: 130 lumens per watt

• 120° Wide Beam Angle

• CRI 80 for balanced color rendering

• Input Voltage: 100–277V

• DLC Premium and ETL Listed

• Rated Lifetime: 50,000 hours

• Slim Profile: Less than 1" thickness
