RAB Lighting
RAB ARXS 95W 18" AEROBAY Linear High Bay Selectable CCT/Wattage
RAB ARXS 95W 18" AEROBAY Linear High Bay Selectable CCT/Wattage
Regular price
$162.00
Regular price
Sale price
$162.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
ARXS Aerobay 1.5FT 95W Hi-Bay Warehouse Light
The AEROBAY offers incredible versatility with options for 4 different sizes, adjustable power and CCT. Perfect for industrial settings, these lights can replace up to 750W MH and can be mounted as high as 50 feet. With an impact-resistant lens, no additional wire guards are necessary. Integrated battery backup is available for standard 120-277V models in case of power loss. Though V-hooks are standard, pendant mount kits can also be used with all models (pendant by others). Carefully select your mounting option when ordering to ensure compatibility.
- Available in following power selectable wattages/sizes:
ARXS : 95W/71W/48W (1.5') - Default 95W
- Adjustable CCT: 4000K/5000K - Default CCT: 4000K
- Voltage rating: 120-277V. 480V available.
- Available with smart control
- Battery backup available
- Pendant mounting kits available for the fixtures and for the battery backup
- 5-year, no compromise warranty
Spec Sheet
Spec Sheet
Family Spec Sheet
Installation Instructions
Sell Sheet
Info
| Product Type | Hi-Bay Lighting |
| Wattage | 48/71/95W |
| Lumen | 6,415-13,085 lm |
| Efficacy | 138 lm/W |
| Color Temp. | 4000K/5000K |
| CRI | 83-85 CRI |
| L70 Lifespan | 100,000 Hours |
| LED's | Multi-chip, high-output, long-life LEDs |
| Housing | Aluminum |
| Finish | Formulated for high durability and long-lasting color |
| Mounting | Comes standard with V-hooks for chain mounting. Accessories available for pendant and surface mounting (purchased separately). |
| Lens | Polycarbonate lens |
| Reflector |
Polyethylene Terephthalate (PET) |
Additional Info
| Dimming Driver | Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10% |
| THD | 9.91% at 120V, 7.86% at 277V |
| Power Factor | 99.4% at 120V, 96.2% at 277V |
| Surge Protection | 6kV |
