20W 4" Surface/Pendant Mount Selectable Wattage/CCT

Pendant Stem Sold Separately

Enhance versatility and value with greater flexibility. The new CD34 has interchangeable optics, offering a sleek 25° beam, a 40° distribution, or a wide 60° option. Easily switch between these options with a simple lens change (sold separately). Optics vary by size, and mounting option. Additional accessories are available for all sizes and distributions. The UL listed CD34 is suitable for both indoor and outdoor use, making it perfect for kitchens, conference rooms, and more. Convert surface mount cylinders to pendant mounts with the included accessory kits, which feature four connectable 12" stems. Clear glass lenses are standard, but frosted options can be purchased for all sizes and finishes.

• Aluminum extrusion housing and die-cast covers available in black, bronze, or white
• Field interchangeable optics sold separately for 25°/40°/60° beam angle
• Field-adjustable color temperature 3000/4000/5000K (indoor); 2700/3000/3500/4000/5000K (outdoor).
• Dimmable on 0-10V systems (indoor); integrated photocell (outdoor)

Spec Sheets

White / Black / Bronze

Family Spec Sheet

Sell Sheet

Installation Instructions

Info

Additional Info
