CW4



The C-WRAP is made of eco-friendly materials and comes in two sizes with selectable features. The design simplifies installation and prevents damage to ceilings. Can be surface mounted or hung from chains with included hardware.



• Field-adjustable wattages: 2 Ft: 22/17/11W (3,000/2,250/1,500lm) 4 Ft: 44/33/22W (6,000/4,500/3,000lm)
• Field-adjustable CCT: 3500/4000/5000K
• Microwave occupancy sensor battery backup options available.
• UL Listed for damp locations
• 0-10V dimming
• 5-Year, no compromise warranty

Spec Sheets

Spec Sheet

Sell Sheet

Installation Instructions

Info

Wattage	22W/33W/44W
Lumen	3,105-6,191
Color Temp.	3500K-5000K
Efficacy	134.8-145.3 lm
CRI	84-85
L70 Lifespan	100,000
Reflector	Refractive Lens
Lens	Diffused Polymethyl Methacrylate (PMMA)
Mounting	Surface mount. Can be mounted with v-hooks (ordered separately).
Housing	Sustainable, bio-composite resin manufactured with coffee chaff, waste seashells, and recycled plastic.
Finish	Naturally occurring, beige, speckled pattern

Additional Info

Electrical Driver 44W: Class P, Constant Current, 120-277V, 50/60 Hz, 120V: 0.38A, 208V: 0.24A, 240V: 0.21A, 277V: 0.16A 33W: Class P, Constant Current, 120-277V, 50/60 Hz, 120V: 0.28A, 208V: 0.19A, 240V: 0.16A, 277V: 0.13A 22W: Class P, Constant Current, 120-277V, 50/60 Hz, 120V: 0.18A, 208V: 0.14A, 240V: 0.11A, 277V: 0.09A Power Factor 99.7% at 120V, 96.2% at 277V THD 5.82% at 120V, 9.99% at 277V Dimming Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
