RAB Lighting

RAB EVC40/LCB EVC Level 2 40A Series with Wi-Fi Electric Vehicle Charger

$709.00

Sale Sold out

Shipping calculated at checkout.

Charging level Level 2 (240v)

Phase type Single-phase

Station type Home charging

Quantity

Electric Vehicle Charger Level 2 40A Series with Wi-Fi

The EVC40/LCB is a reliable and easy-to-use Level 2 charger with Lightcloud Blue control. It features intelligent scheduling for off-peak charging, remote control via a smartphone app, and superior electrical protection even in harsh weather conditions. Compatible with all EVs and PHEVs.

Smart - Works with the Lightcloud Blue app via Wi-Fi connection
Control - On/Off, scheduling charging, view charging session history, and control from anywhere, all from the app.
Indoor/Outdoor Use - Water resistant, NEMA Type 4 enclosure and a cable designed to prevent freezing and cracking in extreme weather.
Easy Install - Wall mountable, plug and play.
Charge any vehicle with an industry standard SAE J1772™ cable and connector

Spec Sheets

Spec Sheet

Family Spec Sheet

Sell Sheet

Installation Instructions

User Guide

Info

Product	EVC Level 2, 40A Series with Wi-Fi
Description	32A / 7.6 kw Residential Charger / 25' Cord / No display, LED indicator light
Output Power	9.6 kW
Power Configuration Settings	Max 40 A
Charging Method	Plug & Play - Level 2 AC Charger
Input Voltage	200-240V, Single Phase
AC Input Connection	NEMA 14-50 plug
Mounting	Wall
Hardwired	No

Additional Info

Input Side Protection	Leakage protection, Over-voltage protection, Over current protection, Under-voltage protection, Short circuit protection, Over temperature protection
Output Side Protection	Leakage protection, Over-voltage protection, Over current protection, Under-voltage protection, Automatic full charge protection, Control pilot fault protection, Short circuit protection, Over temperature protection
Internal Protection	OTP, Relay Welding Detection, CCID Self-Test, MCU Function Fault Detection
Rating of Branch Circuit Breaker	50A
Input Wire Size	8 AWG
Metering Accuracy	Meter IC (1% Accuracy)

Compliance

Listings	ETL Listed
Shock Protection	CCID20. A charging circuit interrupting device (CCID) automatically interrupts the circuit when the current reaches or exceeds the threshold current of 20mA.
OpenADR	No
IP Rating	Ingress protection rating of IP65 for dust and water
NEMA Rating	Type 4, weatherproof protection
California Type Evaluation Program (CTEP)	No
Energy Star Approved	Yes Energy Star ID 3417943
RoHS	Mercury and UV free. RoHS-compliant components.
FCC	Complies with Part 15 of the FCC Rules
