RAB H17XXL 500W LED High Bay Selectable Wattage & CCT

$542.00

Sale Sold out

Shipping calculated at checkout.

Color: Black

Wattage 500W

Color Temperature Selectable CCT

Quantity

500W H17XXL UFO High Bay

The newest generation of the H17 may be smaller and lighter, but it still packs a powerful punch. With a body size less than a foot in diameter, the entire family offers incredibly high output, replacing up to 1500W MH at an even higher efficacy. Plus, there are now four models to choose from including two new power packages, making it even more versatile for any application. Experience even more control with three selectable wattages and three CCTs. The H17 also features an expansion port for easy addition of standard or Lightcloud Blue-enabled PIR and microwave sensors, allowing for customized brightness and hold time settings for energy and cost savings. For added convenience, a remote is also available. Emergency battery backup? No problem. With Lightcloud Blue technology, you can easily conduct monthly and annual testing right from your phone, saving valuable time. And to top it off, there are a variety of accessories such as reflectors, refractors, lenses, wire guards, and mounting options to choose from.

Selectable power, and CCT
Available models & wattages: H17XXL: 500/400/300W
Selectable CCT: 3000/4000/5000K adjustable
Suitable for wet locations
Comes with expansion port for sensors
PIR and microwave sensor kits available
Kits available for surface mount or pendant mount
DLC Premium listed
5-years, limited warranty
Available accessories: Aluminum and polycarbonate reflector,
wire guard and drop lens available for H17S, H17, H17XL
Aluminum reflector, wire guard available for H17XXL

Info

Product Type	UFO High Bay
Wattage	300/400/500W
Lumen	49,020-79,203 lm
Efficacy	147.3-178 lm/W
Color Temp.	3000K 4000K 5000K
CRI	81-84 CRI
L70 Lifespan	100,000-hour
Housing	Precision die-cast aluminum
Finish	Black \| White
Mounting	Comes standard with a hanging hook and a 6-foot cord. Heavy-duty 3/4"-14 NPT hook and 3/4"-14 pendant mount capable (pendant by others)
Reflector	Polycarbonate and Aluminum (Reflector Accessories Sold Separately)
Lens	Polycarbonate lens
IP Rating	Ingress protection rating of IP65 for dust and water

Additional Info

Compliance

UL Listed	Suitable for wet locations. Ingress protection rating of IP65 for dust and water
IESNA LM-79 & LM-80 Testing	RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed	This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements. DLC Product Code: S-YB69RP

Electrical

Driver	See Spec Sheets
THD	See Spec Sheets
Power Factor	See Spec Sheets
Dimming Driver	Driver includes wiring for 0-10V dimming systems. Dim as low as 10%
Photocell	120-277V selectable photocell that can be turned on and off
