RAB Lighting
RAB MVS50 15M Low Voltage MVS Sensor
RAB MVS50 15M Low Voltage MVS Sensor
Couldn't load pickup availability
RAB MVS50 Occupancy Sensor: Precision Lighting Control
The RAB MVS50 occupancy sensor offers advanced lighting control, ideal for both indoor and outdoor environments. Designed for high ceilings, this sensor ensures efficient energy usage and optimal lighting management.
Featuring dual-technology detection, the MVS50 accurately senses motion across a 50ft range. This makes it a reliable choice for large spaces requiring precise lighting control.
With its low voltage operation and 0-10V dimming capability, the RAB MVS50 integrates seamlessly into modern lighting setups, enhancing both functionality and energy efficiency.
This occupancy sensor is crafted to meet the demands of technical and professional installers, ensuring a straightforward installation process and reliable performance.
- Dual-technology motion detection
- 50ft sensing range
- 0-10V dimming compatibility
- Designed for high ceilings
- Indoor and outdoor use
Spec Sheet
White / Black
Installation Instructions
Info
| Sensor Connection Type | Pogo pin |
| Max Mounting Height | 50 ft |
| Detection Range | 50 ft diameter mounted at 50 ft |
| Sensor Technology | Microwave (MVS) |
| Default Setting | Motion Sensitivity: High |
| Brightness when triggered | 100% |
| Hold time | 20 minutes |
| Standby to dim | 20% |
| Standby time | 1 minute |
| When vacant | Off |
| Daylight | Disabled |
| Adjustable Sensor Settings | Yes, using the MSR1 Remote (sold separately) |
| Standby to dim | 10%/20%/30%/50% |
| Standby time | 0s/10s/30s/1min/5min/10min/30min/60min/+∞ |
| Daylight Threshold | 2Lux/10Lux/30Lux/50Lux/80Lux/120Lux/Disable |
