RAB Lighting

RAB SLIMXS 25W LED Wallpack Selectable Wattage/CCT & Photocell

RAB SLIMXS 25W LED Wallpack Selectable Wattage/CCT & Photocell

Regular price $158.00
Regular price Sale price $158.00
Sale Sold out
Shipping calculated at checkout.
Color: Bronze
Wattage
Color Temperature

25W Wall Pack Selectable Wattage /CCT & Photocell

Experience exceptional performance and precise optics control with the RAB SLIMXS 25W LED Wallpack. Our innovative 5-position aiming system allows you to direct light exactly where you need it, while maintaining full cutoff compliance. With four different footprints and field-adjustable CCT and wattage options, the SLIM family offers versatility to match all your lighting needs, from walkways to loading docks. And with sustainability in mind, the SLIM's lightweight and slim design, raw aluminum back, full cutoff optics, and integrated photocell help reduce energy costs and light pollution. Choose from a variety of models, including DarkSky certified and DLC LUNA listed options, all with a sophisticated and exclusive tone that exudes elegance and exclusivity. Installation and maintenance are made easy with top-access latches, making the SLIMXXS the perfect choice for your luxury lighting needs.



  • Available with adjustable wattages: XS: 25/18/12W - Factory default 18W
  • Field-adjustable CCT: 3000K/4000K/5000K - Factory default 4000K
  • Static CCT models available: 3000K
  • Adjustable forward throw: -20°/-10°/0°/10°/20° - factory default 0°
  • Integrated on/off photocell
  • 0-10V dimming
  • UL rated for wet locations
  • IP65 rated
  • 5-year, no-compromise warranty

   Field Adjustable Logo

Spec Sheet

White / Bronze

Family Spec Sheet

Sell Sheet

Installation Instructions

Info
Product Type  Full Cutoff Wall Pack
Efficacy 116.1-142.9 lm/W
Wattage 12/18/25W
Lumen 1382-3444 lm
Color Temp. 30K/40K/50K
CRI 80-83 CRI
Lifespan 100,000 Hours
Finish  Bronze/White



    Additional Info
    Dim to Off Yes
    Power Factor 99.1% at 120V
    Driver 25W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.20A, 208V: 0.13A, 240V: 0.11A, 277V: 0.10A
    18W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.14A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A
    12W: Constant Current, Class 1, 120-277V, 50/60 Hz, 120V: 0.09A, 208V: 0.08A, 240V: 0.07A, 277V: 0.06A
    Dimming Driver
    Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%
    Photocell
    120-277V selectable photocell that can be turned on and off.
