RAB T34FA1X4 40W LED Backlit 1X4 Drop Ceiling Flat Panel Selectable CCT/Wattage

RAB T34FA1X4 40W LED Backlit 1X4 Drop Ceiling Flat Panel Selectable CCT/Wattage

$276.00
$276.00
Sale Sold out
Shipping calculated at checkout.
Style

1X4 Backlit Flat panel Selectable CCT

Please note these items can only be ordered in increments of 4

  • 0-10V dimming
  • 50,000-Hour LED lifespan
  • 5-Year, limited warranty
  • 4 per case, must order in case quantity increments

Spec Sheets

Spec Sheet

Installation Instructions

Info


Wattage 20/30/40W
Lumen 2137-4089 lm
Color Temp. 3500K-5000K
Efficacy 113.2-127.8 lm/W
Voltage 120-277V
CRI 82-84 CRI
L70 Lifespan 50,000 Hours
Finish  Formulated for high durability and long-lasting color
Lens Frosted polystyrene
Mounting Recessed into T-grid ceiling. Surface and recessed mounting kits available for drywall ceilings.
Housing Plastic frame & galvanized steel back housing

Additional Info

 Compliance

Safety Listing UL Listed Suitable for damp locations
Environment/Fixture Rating Damp Location
IC Rated Suitable for direct contact with insulation
DLC Listed This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-4H7PK2


Electrical
Driver 20W: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.17A, 208V: 0.10A, 240V: 0.09A, 277V: 0.08A
30W: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.25A, 208V: 0.15A, 240V: 0.13A, 277V: 0.11A
40W: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.34A, 208V: 0.20A, 240V: 0.17A, 277V: 0.15A
Dimming driver Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD 6.87% at 120V, 9.66% at 277V
Power Factor 99.54% at 120V, 94.8% at 277V
Operating Temperature -30°C (-22°F) to 40°C (104°F)
Dimming 0-10V Dimming
