RAB Lighting
RAB WPLEDL 113W Outdoor Wall Pack Selectable Wattage & CCT With Photocell
RAB WPLEDL 113W Outdoor Wall Pack Selectable Wattage & CCT With Photocell
Regular price
$285.00
Regular price
Sale price
$285.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
113W LED Outdoor Wall Pack
The redesigned LPACK is smaller, lighter, and sleeker with selectable wattage and color temperature. It also includes an on/off photocell for added flexibility. This fully shielded wall pack offers environmentally friendly lighting, easy installation, and reduces light pollution and glare.
- Selectable wattages 113W/85W/58W
- Selectable CCT: 3000K/4000K/5000K
- Selectable on/off photocell.
- Optional Lightcloud Blue-enabled MVS motion sensor
- Voltage ratings: 120-277V
- Comes with integrated junction box
- Suitable for wet locations
- 5-Year, no-compromise warranty
Spec Sheet
Spec Sheet
Installation Instructions
Info
| Product Type | Wall Pack W/ Integrated Photocell |
| Wattage | 58/85/113W |
| Lumen | 7,533-14,968 lm |
| Color Temp. |
3000K/4000K/5000K |
| CRI | 83-85 CRI |
| Lifespan | 100,000 Hours |
| Housing | Die-cast aluminum |
| Finish | Bronze, White |
| Mounting | Integrated junction box for wall mounting. |
| Reflector | Specular vacuum-metallized polycarbonate |
| Gaskets | High-temperature silicone gaskets |
| IES Classification | The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It is intended to be located near the side of the area, allowing the light to project outward and fill the area |
| Lens | Tempered glass lens |
| LED | Multi-chip, high-output, long-life LEDs |
| IP Rating | Ingress protection rating of IP66 for dust and water |
