RAB WPLEDM 32W LED Wallpack Selectable Wattage & CCT

RAB WPLEDM 32W LED Wallpack Selectable Wattage & CCT

$156.00
$156.00
Sale Sold out
Shipping calculated at checkout.
Color: Bronze
Wattage
Color Temerperature

WPLEDM 32W CCT Adjustable Wallpack



The redesigned LPACK offers a more compact and sustainable design that is 50% lighter and has a smaller overall form size. It also features selectable wattage and color temperature, eliminating the need for multiple SKUs. With an included photocell and easy installation options, the LPACK provides eco-friendly lighting with reduced glare and light pollution.



  • Selectable wattages: WPLEDM: 32W/24W/16W
  • Selectable CCT: 3000K/4000K/5000K
  • Selectable on/off photocell
  • Voltage ratings: 120-277V
  • Comes with integrated junction box
  • Suitable for wet locations for downlight application
  • 5-Year, no-compromise warranty

  Field Adjustable Logo



Spec Sheet

Bronze Spec Sheet

White Spec Sheet

Family Spec Sheet

Sell Sheet

Installation Instructions

Info
Product Type  Wall Pack
Wattage Selectable 16/24/32W
Efficacy 123.5-148.3 lm/W
Lumen 2,020-4,151
Color Temp. 3000/4000/5000K
CRI 83-84 CRI
Lifespan 100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Finish  Bronze
Full Cutoff Allows for conformance to the IDA's fully shielding requirement, emitting no light above 90 degrees.
Housing
 Die-cast aluminum
Lens Acrylic lens
Reflector
High reflection polycarbonate
Mounting
Integrated j-box and an optional wall plate included.



    Additional Info
    THD 6.58% at 120V, 11.18% at 277V
    Power Factor 99.5% at 120V, 92.3% at 277V
    Dimming Driver Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
    Driver
    		 32W: Constant Current, Class 2, 120-277V, 50/60 Hz,120V: 0.26A, 208V: 0.16A, 240V: 0.14A, 277V: 0.12A
    24W: Constant Current, Class 2, 120-277V, 50/60 Hz,120V: 0.19A, 208V: 0.12A, 240V: 0.10A, 277V: 0.09A
    16W: Constant Current, Class 2, 120-277V, 50/60 Hz,120V: 0.13A, 208V: 0.08A, 240V: 0.07A, 277V: 0.06A
    Photocell
    Integrated photocell included with on/off switch
    Surge Protection
    L-L 2kV; L-G 4kV
    Dim to Off
    Yes
