RAB Lighting

RAB WPX2 80W LED Wallpack Selectable Wattage/CCT

RAB WPX2 80W LED Wallpack Selectable Wattage/CCT

Regular price $242.00
Regular price $195.00 Sale price $242.00
Sale Sold out
Shipping calculated at checkout.
Color: Bronze
Wattage
Color Temperature

WPX2

  • 100,000-Hour LED lifespan
  • 10-Year, no-compromise warranty
  • Premium wall pack available in three different sizes and selectable wattages: WPX1: 30/20/15W WPX2: 80/60/40W WPX3: 130/100/65W
  • CCT Adjustable: 3000/4000/5000K
  • Selectable on/off photocell 120-277V & 480V
  • 0-10V dimming standard
  • Battery backup available for 120-277V models
  • Available with smart controls.
  • Multi-sensor remote sold separately
   Field Adjustable Logo



Spec Sheet

Spec Sheet

Family Spec Sheet

Installation Instructions

Info
Product Type  Wall Pack
Efficacy
134.1-152.6 lm/W
Wattage Selectable 80/60/40W
Lumen 5,789-11,353 lm
Color Temp. 3000K/4000K/5000K
CRI 82-84 CRI
Lifespan 100,000 Hours
Finish  Bronze/White



    Additional Info
     Construction
    Housing Aluminum alloy
    Mounting Hinged wiring access and conduit entries on the back sides, top and bottom make installation a snap
    Lens Prismatic, heat-resistant borosilicate glass
    Reflector Aluminum
    Max/Min Temperature
    The minimum starting temperature is -40°C (-40°F)
    Suitable for use in up to 40°C (104°F)
    Gaskets High-temperature silicone
    Finish
    Formulated for high durability and long-lasting color
                                                    Compliance
    UL Listed Suitable for wet locations
                                                      Electrical
    Driver

    Constant Current, Class 2, 120-277V, 50/60 Hz

    80W: 120V: 0.66A 208V: 0.39A, 240V: 0.33A, 277V: 0.30A

    60W: 120V: 0.48A 208V: 0.29A, 240V: 0.25A, 277V: 0.23A

    40W: 120V: 0.34A 208V: 0.19A, 240V: 0.17A, 277V: 0.16A

    Dimming Driver Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
    Photocell
    Integrated photocell included with on/off switch
    Surge Protection
    4kV
