RAB Lighting

RAB X34S 35W LED Flood Light Selectable CCT/Wattage

$93.00

Sale Sold out

Shipping calculated at checkout.

Color Bronze White

Mount Style Knuckle Mount

Color Temperature Selectable CCT

Quantity

X34S 35W 4500 Lumen Flood Light Selectable CCT/Wattage

White on Backorder until October 28, 2024.

Click Here for possible alternative.

Bronze	Spec Sheet
White	Spec Sheet

Product Type	Flood Light Field Adjustable
Wattage	35/25/20W
Lumen	2,685-4,677 lm
Color Temp.	3000K 4000K 5000K
CRI	81-84 CRI
L70 Lifespan	100,000 Hours
Housing Material	Die-cast aluminum
Finish	White \| Bronze
Mounting	Knuckle mount
Reflector	Polycarbonate
Lens	Glass
Beam Angle	NEMA Beam Spread of 7H x 7V

Compliance

UL Listed	Suitable for wet locations
IESNA LM-79 & LM-80 Testing	RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating	Ingress protection rating of IP65 for dust and water
DLC Listed	This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements. DLC Product Code: S-T9KEIS

Electrical

Driver	Constant Current, Class 1, 120/277V, 50/60 Hz 35W: 120V: 0.30A, 277V: 0.13A 25W: 120V: 0.22A, 277V: 0.10A 20W: 120V: 0.18A, 277V: 0.08A
THD	35W: 4.3% at 120V, 8.2% at 277V 25W: 5.0% at 120V, 16.8% at 277V 20W: 6.1% at 120V, 20.5% at 277V
Power Factor	35W: 99.7% at 120V, 96.2% at 277V 25W: 99.7% at 120V, 91.7% at 277V 20W: 99.4% at 120V, 90.6% at 277V
Surge Protection	2kV
Photocell	Integrated photocell included with on/off switch
