Rayhil

RAYHIL RAD10 5W 1" Mini Recessed LED Downlight 27K/30K/35K/40K

RAYHIL RAD10 5W 1" Mini Recessed LED Downlight 27K/30K/35K/40K

Regular price $55.99
Regular price $59.99 Sale price $55.99
Sale Sold out
Shipping calculated at checkout.
Size
Style
Color Temperature
Quantity

Rayhil RAD10 5W 1" Mini Recessed LED Downlight 27K/30K/35K/40K

The Rayhil RAD10 is a 1" mini recessed LED downlight in round or square with selectable CCT (27K, 30K, 35K, 40K). It is air-tight, damp location approved and Type IC rated for direct contact with insulation, so a downlight housing is not required even in insulated ceilings.

  • Air-tight and damp location approved
  • Type IC rated - approved for direct contact with insulation
  • Downlight housing is not required even for insulated ceilings
  • Not compatible with dimmable drivers
  • Spring loaded mounting clips
  • Selectable CCT (27K/30K/35K/40K)
  • Round/Square
  • 5 year warranty

*Message us for Construction Plates

Square Dimensions
Length (in.) 1.57"
Width (in.) 1.57"
Height (in.) 1.72"
Round Dimensions
Circ. (in.) 1.57"
Height (in.) 1.72"
Spec Sheets

Spec Sheet

Info
Voltage 24V
Wattage 5W
Lumen 400lm
Efficacy(LPW) >60 lm/W
Color Temp 27K/30K/35K/40K
CRI >90
Beam Angle 25°
Dimming Non-Dimming
Lamp Life 50,000hr
Environment Damp Location
