Lotus LED
LOTUS LD4R-HO-IT 4" 18W Round Deep Regressed Trimless Downlight Selectable CCT
LOTUS LD4R-HO-IT 4" 18W Round Deep Regressed Trimless Downlight Selectable CCT
Regular price
$138.11
Regular price
Sale price
$138.11
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Lotus LED LD4R-HO-IT 4" 18W Deep Regressed LED Trimless Downlight
The LOTUS 18W LD4R-HO-IT Deep Regressed LED offers a sleek, glare-free design with interchangeable trims featuring premium finishes. Its compact 3 1/2″ thickness fits tight ceiling spaces without needing housing. Equipped with armored cable and metal connectors, it’s rated for open plenum, air-tight, and wet locations. Compatible with most CL dimmers and available with 0-10V dimming, it supports 120V to 347V input. Choose from multiple color temperatures, including user-selectable 5CCT option. With a range of light outputs and beam angles, plus a 10-year residential warranty, it’s a reliable, energy-efficient lighting solution.
- 18W LD4R-HO-IT
- Deep Regressed LED – Elegant Design Without Glare
- Interchangeable Trims With High End Finishes
- Armoured Cable & Metal Connectors – Open Plenum Rated
- Type IC, Air-Tight & Wet Location – No Housing Required
- 3 1/2″ thick – fits in limited ceiling space
- Triac Dimmable with most CL dimmers 120V input
- 0-10V Dimmable Option 120V – 347V input
- 5CCT user selectable
- Light output 18W: 2700K-1500 lm, 3000K-1550 lm, 3500K-1600 lm, 4000K-1650 lm, 5000K-1700 lm
- Beam Angle: 30° (default), 15° & 60° optional
- Driver Inside Connection Box with Romex Quick Connectors
- Warranty: 10 Year Residential, 5 Year Commercial Installations
Spec Sheet
Spec Sheet
Info
| Applications | Recessed Ceiling Mount Trimless |
| Wattage | 18W |
| Lumen | 1600L |
| CRI | 90+ |
| CCT | 27K-50K |
| Voltage | 120V |
| Beam Angle | 36° (15° & 60° Purchases separately) |
| Dimming | Triac Dimmable |
| Dimensions | W/L 4 7/16"" H 4 1/2" |
| Cutout | 3.50" |
Additional Info
| Airtight | Yes |
| Location Rating | Insulated Ceilings, Open Plenum, Wet Locations |
| IC Rated | Yes |
| Certifications | cETLus |
| Warranty | 10 Year Residential / 5 Year Commercial |
