Emcod MLE60-24DC-UD 60W 24V DC Driver
Emcod MLE60-24DC-UD 60W 24V DC Driver
Regular price
$119.99
Regular price
$129.99
Sale price
$119.99
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
60W Class 2 Electronic Dimming Driver
The Emcod MLE60-24DC is a 60W Class 2 Electronic Dimming Driver capable of delivering power efficiently with optimal performance. With a 24V DC output this device provides reliable automation in commercial, industrial and residential applications. The Driver is ideal for outdoor electronic applications. It is UL-listed and comes with a black powder coated steel enclosure.
- 24V DC Constant voltage 60W hardwire LED drivers
- 5-in-1 with Triac forward and reverse phase, 0/1-10V , resistor, PWM
- Input leads are 18AWG 600V
- Output leads are 16AWG 300V
Spec Sheet
Spec Sheet
Installation Instructions
Info
| SERIES MLE-24DC | |
|---|---|
| Dimensions | |
| Weight | 2.50 LBS |
| Length | 6.79" |
| Width | 4.47" |
| Height | 1.38" |
| Electrical |
|
| Input Voltage |
100-277V AC |
|
Output Voltage |
24VDC |
| Max Load |
60W |
| Rating | cULus Listed (Wet Location) |
Additional Info
| Knockouts | Wiring compartment has 6 knockouts sizes for 3/8 inch screw cable connectors |
| Input Voltage | 100-277V 50/60Hz |
| Max. input current at full load | 0.3A |
| Output voltage without load | 24.1VDC |
| Output voltage fully loaded | 24VDC |
| Max. Total Wattage | 60W Max |
| Max. Output Current | 2.5A |
| Efficiency | 87% |
| Load regulation | 1% |
| Ripple | 5% |
