NeoVISION120 120V TopFlex Neon Tape
120VAC operation for higher power and brightness. Flexible linear “neon” tape is designed for applications that require ultra-rich light and color saturation that is characteristic of neon. TopFlex enables lighting along straight or inward/outward curved surfaces. NeoVision120 tapes provide long, continuous runs up to 163 feet.
Click Here for Accessories
- 120VAC operation (no driver required)
- 3.4W per foot (colors) or 4.3W per foot (white)
- Wet location – IP65
- Multiple power feed options
- Tape encased in UV stable silicone (UV protected)
- Triac/ELV Dimmable
- 2700K, 3000K or 4000K white / Amber, Blue, Green or Red
- 120° viewing angle
- Maximum run: 163′
- Made to order in 12” increments
Spec Sheets
Spec Sheet
Installation Instructions
Info
Catalog No. | Lumens per Foot | CRI | Color Temp. | Max. Run |
---|---|---|---|---|
NV120T-4W-27K-FT | 232 | 90+ | 2700K | 163′ |
NV120T-4W-30K-FT | 255 | 90+ | 3000K | 163′ |
NV120T-4W-40K-FT | 257 | 90+ | 4000K | 163′ |
NV120T-3W-AM-FT | 59 | 90+ | AMBER | 163′ |
NV120T-3W-BL-FT | 34 | 90+ | BLUE | 163′ |
NV120T-3W-GR-FT | 194 | 90+ | GREEN | 163′ |
NV120T-3W-RD-FT | 94 | 90+ | RED | 163′ |
Accessories
Catalog No. | Description |
---|---|
NV120T-HW-8-EF | Hardwire End Feed w/Filter & 8A Fuse |
NV24T-PF-BF8 | Tape to power flexible bottom feed – 8 ft. length |
NV120T-HW-8-BF | Hardwire Bottom Feed w/Filter & 8A Fuse |
NV120T-PC-8-EF | Plug-in End Feed w/Filter & 8A Fuse |
NV120T-PC-8-BF | Plug-in Bottom Feed w/Filter & 8A Fuse |
NV120T-MC-FC | Front Clip, 20 Clips/40 Screws |
NV120T-MC-A | Back Mounting Clip, 20 Clips/20 Screws |
NV120T-CHL-A4 | 4 ft Channel with 4 Screws |
NV120T-CHL-A8 | 8 ft Channel with 8 Screws |
NV120T-FLEX-CHL-10 | SideFlex 10 ft Channel with 22 Screws |
